MEMS Variable Optical Attenuator (MEMS VOA)
Features
Low insertion loss
Compact design
Low polarization dependent loss
Low energy consumption
Application
Channel switch
Receiver protection
EDFA gain slope control
Optical splitter multiplexer
Power control and equalization
Technical parameters
|
Parameters |
MEMS VOA |
Unit |
|
|
Type |
Bright |
Dark |
|
|
Operating Wavelength |
SM:1260~1620；MM:850/1310 |
nm |
|
|
Attenuation Range |
SM:≥30@5V；MM: ≥30@3V |
dB |
|
|
Insertion Loss |
≤0.7 |
dB |
|
|
Response Time |
≤8 |
ms |
|
|
Return Loss |
SM≥50；MM≥30 |
dB |
|
|
WDL |
≤0.25@0V |
dB |
|
|
Optical Power |
≤500 |
mW |
|
|
Driving Voltage |
SM≤6.5；MM≤35 |
V |
|
|
Operating Temperature |
-20~+85 |
℃ |
|
|
Storage Temperature |
-40~+85 |
℃ |
|
|
Dimension |
Φ5.4×19 |
mm |
|
Dimensions
Pin Assignment
|
Pin NO. |
Single Mode |
Multi-Mode |
|
1 |
Anode |
Anode |
|
2 |
Cathode |
GND |
|
3 |
GND |
GND |
Order information: HC－MVOA -A-B-C-D-E-F-G
|
A |
B |
C |
D |
E |
F |
|
Type |
Wavelength |
Attenuation Range |
Fiber Dimension |
Fiber Length |
Connector |
|
1: Bright |
1:C band |
25:min.25 dB |
025:Φ0.25mm |
05:0.5m |
00: None |
|
2 :Dark |
2:L band |
30:min.30 dB |
09:Φ0.9mm |
10:1.0m |
FP: FC/UPC |
|
|
3:C &L band |
40:min.40dB |
X:other |
15:1.5m |
FA: FC/APC |
|
|
4:M Multi-Mode |
X:other |
|
X:other |
SP: SC/UPC |
|
|
X:other |
|
|
|
SA: SC/APC |
|
|
|
|
|
|
LP: LC/UPC |
|
|
|
|
|
|
LA: LC/APC |
|
|
|
|
|
|
X:other |
If you need more support , Please contact us.
