1x2 CWDM Device(3 Ports)

1x2 CWDM Device (3 Ports) is widely used in fibre optic communications, data centres, telecommunication networks, etc. It can effectively improve network performance and bandwidth utilisation.

Specification

Resources

Features

High isolation: Reduces interference between wavelengths.

Low insertion loss: Ensures high signal transmission efficiency.

Three-port design: Includes one input port and two output ports, or vice versa.

Wavelength Splitting: Separates or combines optical signals of different wavelengths.

CWDM technology: Supports Coarse Wavelength Division Multiplexing (CWDM), typically covering 18 wavelengths (1270nm to 1610nm).

Applications

CATV system: Separate or merge signals of different channels.

Data Centre: Optimise internal data transmission and improve network efficiency.

Test and Measurement: For testing and monitoring of optical communication equipment.

Telecommunication Network: Expand transmission capacity in backbone and metro networks.

Optical fibre communication: for metropolitan area networks and access networks to improve fibre optic bandwidth utilisation.

Technical Specification

Parameters	Unit	HC-CWDM Device
Wavelength Range	nm	1260 ~ 1620
Channel Center Wavelength	nm	1270 / 1290 / … / 1610 or 1271 / 1291 / … / 1611
Channel Spacing	nm	20
Channel Passband	nm	λc ± 7.5
Insertion Loss	dB	Transmission: ≤0.6
		Reflection: ≤0.4
Adjacent Channel Isolation	dB	≥ 30
Non-adjacent Channel Isolation	dB	≥ 40
Reflection Channel Isolation	dB	≥ 15
PDL	dB	≤ 0.1
Wavelength thermal stability	nm/℃	≤ 0.003
Insertion loss thermal stability	dB/℃	≤ 0.005
Return loss	dB	≥ 45
Optical Power	mW	≤ 500
Operating Temperature	℃	-10 ~ +70
Storage Temperature	℃	-40 ~ +85
Relative Humidity	%	5 ~ 95
Dimension	mm	Φ5.5×38	Φ4.0×25
Note: 1. Customization is available. 2. Specified without connector, and add an additional 0.2dB loss per connector.

* 1、Above specifications are for devices without connector.

2、Specifications may change without notice.

Dimension (Unit:mm)

Φ5.5×38 mm

Φ4.0×25 mm

Ordering Information HC－CWDM－A－B－C－D - E

Channel Center Wavelength

Tube Type

Fiber Length

(Include connector)

Connector

Dimension

Txxxx: xxxxnm

(xxxx =Channel Center Wavelength)

eg. T1470: 1470nm

25:250um

90:900um

X: Others

05: 0.5m±0.05m

10: 1.0m±0.05m

15: 1.5m±0.05m

X: Others

OO:None

FP: FC/PC

FA: FC/APC

SP: SC/PC

SA: SC/APC

STP: ST/PC

LP: LC/PC

LA: LC/APC

X: Others

5534:

Φ5.5×34mm

4225:

Φ4.2×25mm

X: Others

If you need more support , Please contact us .
