CWDM Module Cartridge
Technical Parameter
|
Parameter |
4 Channel |
8 Channel |
16 Channel |
18 Channel |
|
|
Mux/Demux |
Mux/Demux |
Mux/Demux |
Mux/Demux |
||
|
Channel Wavelength（nm） |
1270~1610/1271~1611 |
||||
|
Center wavelength Accuracy (nm) |
±0.5 |
||||
|
Channel Spacing（nm） |
20 |
||||
|
Channel Passband (@-0.5dB bandwidth (nm) |
+/-7.5/+/-6.5 |
||||
|
Insertion Loss (dB) |
≤1.5 |
≤2.5 |
≤3.5 |
≤3.5 |
|
|
Channel Uniformity (dB) |
≤0.6 |
≤1.0 |
≤1.5 |
≤1.5 |
|
|
Channel Ripple (dB) |
0.3 |
||||
|
Isolation（dB） |
Adjacent |
>30 |
|||
|
Non-adjacent |
>40 |
||||
|
Insertion Loss（dB） |
Express with filter |
>30 |
|||
|
Express without filter |
>12 |
||||
|
Inertion Loss Temperature Sensitivity (dB/℃) |
<0.005 |
||||
|
Wavelength Temperature Shifting (nm/℃) |
<0.002 |
||||
|
Polarization Dependent Loss（dB） |
<0.1 |
||||
|
Polarization Mode Dispersion（ps） |
<0.1 |
||||
|
Directivity (dB) |
＞50 |
||||
|
Return Loss（dB） |
＞45 |
||||
|
Maximum Power Handling (mW) |
300 |
||||
|
Opterating Temperature (℃) |
-40~+85 |
||||
|
Storage Temperature (℃) |
-40~+85 |
||||
|
Package dimension (mm)(LGX box) |
L155.5xW102(129)xH29 |
||||
Notes: 1、Above specifications are for devices without connector.2、Specifications may change without notice.
Dimension (Unit:mm)
Order information：HC-CWDM-A-B-C-D-E-F
|
A |
B |
C |
D |
E |
F |
|
Number of Channels |
Configuration |
Fiber Type |
Fiber Length |
Connector |
1st Channel |
|
04: 4 Channels |
01:MUX |
01: Bare fiber |
01:1m |
01: None |
27:1270nm |
|
08: 8 Channels |
02:DEMUX |
02: 900um loose tube |
02:2m |
02:FC/APC |
29:1290nm |
|
16:16 Channels |
03:OADM |
03: 2mm Cable |
03: Specify |
03:FC/UPC |
47:1470nm |
|
18: 18 Channels |
04: 3mm Cable |
04:SC/APC |
49:1490nm |
||
|
0N: N Channels |
05:SC/UPC |
57:1570nm |
|||
|
06:LC |
61:1610nm |
||||
|
07:ST |
07: special |
