Product introduction
The butterfly-shaped SOA is packaged by 14Pin and can be used for an optical fiber sensing system and an optical communication transmission system.
Specification parameters
Working conditions | Minimal | Typical | Max | Unit | |
Operating current | 250 | 400 | mA | ||
Operating voltage | 1.6 | 1.8 | V | ||
Bandwidth | -3dB | 45 | nm | ||
Operating wavelength | 1500 | 1580 | nm | ||
Saturated optical power | If=250mA | 11 | dBm | ||
Small signal gain | Incoming optical power = -20 dBm | 20 | dB | ||
Noise figure | 7 | dB | |||
Polarization dependent gain | 1.8 | dB | |||
Thermistor | 25℃ | 10 | kΩ | ||
TEC operating current | 1.5 | A | |||
TEC operating voltage | 3.5 | V | |||
Operating temperature | 0 | 70 | ℃ | ||
Storage temperature | -20 | 85 | ℃ | ||
Total power consumption | 4 | W | |||
Connector | Customized | FC/APC | |||
Fiber length | Customized | 1 | m |
